产品详情

12CrNi3钢属于合金渗碳钢，比12CrNi2A钢有更高的淬透性，因此，可以用于制造比12CrNi2A钢截面稍大的零件。该钢淬火低温回火或高温回火后都具有良好的综合力学性能，钢的低温韧性好，缺口敏感性小，切削加工性能良好，当硬度为HB260～320时，相对切削加工性为60%～70另外，钢退火后硬度低、塑性好，因此，既可以采用切削加工方法制造模具，也可以采用冷挤压成型方法制造模具。为提高模具型腔的耐磨性，模具成型后需要进行渗碳处理，然后再进行淬火和低温回火，从而保证模具表面具有高硬度、高耐磨性而心部具有很好的韧性，该钢适宜制造大、中型塑料模具。但该钢有回火脆性倾向和形成白点的倾向。

特性及适用范围
是用途较广的高级渗碳钢，与15Cr、20Cr钢相比，其强度、塑性、淬透性均高。主要用来制作重负荷条件下要求高强度，高硬度和高韧性的主轴及要求中心韧性很高或承受冲击负荷、表面耐磨、热处理变形小的轴、杆以及在高速和冲击负荷下工作的各种传动齿轮、调节螺钉、凸轮轴

化学成份
硅 Si：0.17～0.37
锰 Mn：0.30～0.60
硫 S ：允许残余含量≤0.035
磷 P ：允许残余含量≤0.035
铬 Cr：0.60～0.90
镍 Ni：2.75～3.15
铜 Cu：允许残余含量≤0.030

力学性能
抗拉强度 σb (MPa)：≥930(95)
屈服强度 σs (MPa)：≥685(70)
伸长率 δ5 (%)：≥11
断面收缩率 ψ (%)：≥50
冲击功 Akv (J)：≥71
冲击韧性值 αkv (J/cm2)：≥88(9)
硬度：≤217HB
试样尺寸：试样毛坯尺寸为15mm
●热处理规范及金相组织：
热处理规范：淬火:第一次860℃,第二次780℃,油冷;回火200℃,水冷、空冷。

●交货状态：以热处理（正火、退火或高温回火）或不热处理状态交货，交货状态应在合同中注明。

12CrNi3 steel is alloyed with carbon steel, which has a higher quenching property than 12CrNi2A steel. Therefore, it can be used to manufacture parts that are slightly larger than the 12CrNi2A steel. The hardened steel tempered at low temperature or high temperature tempering after has good comprehensive mechanical properties and good low temperature toughness of the steel, the small notch sensitivity, good cutting properties. When the hardness is HB260 to 320, relative machinability is 60% ~ 70 also low hardness of steel after annealing, good plasticity. Thus, the utility model can by cutting machining method to manufacture the mold, can also be used in cold extrusion molding method for manufacturing mold. In order to improve the wear resistance of the mold cavity, the mold needs for carburization, and then quenched and tempered at low temperature, so as to ensure the mold surface with high hardness, high wear resistance and heart department has a very good toughness, the steel suitable large and medium-sized plastic mold manufacturing. But the steel temper brittleness tendency and the formation of white spots.
Characteristic and applicable scope
It is widely used in high - carbon steel, compared with 15Cr and 20Cr steel, the strength, plasticity and quenching of the high - carbon steel are high. Mainly used to produce high strength requirements under the condition of heavy load, high hardness and high toughness of spindle and center toughness is high or under impact load, surface abrasion resistance, heat treatment deformation small shaft, rod and under high speed and impact load of various transmission gear, adjusting screw, a cam shaft
Chemical composition
Silicon Si:0.17 ~ 0.37
Mn Mn:0.30 ~ 0.60
S: allow residual sulfur content less than 0.035
P P: allow residual content less than 0.035
Chrome Cr:0.60 ~ 0.90
Nickel Ni:2.75 ~ 3.15
Cu: allow residual copper content is less than 0.030
Mechanical properties
The ultimate tensile strength of B (MPa): 930 (95)
Yield strength s (MPa): 685 (70)
5 elongation (%): 11
Section shrinkage (%): 50 psi
The impact of Akv (J): 71
The impact toughness value of alpha kV (J/cm2): 88 (9)
Hardness: 217HB
Sample size: the sample size is 15mm
The specification of heat treatment and microstructure:
Heat treatment specification: quenching: the first 860, 780 second, oil cooling, tempering 200, water cooling, air cooling.
] delivery status: to heat treatment (normalizing, annealing or tempering) with or without heat treatment delivery, delivery status should be indicated in the contract.

江苏苏州倍徕斯金属供应东北抚顺特钢12CrNi3A圆钢，大冶特钢12CrNi3A圆棒，重特12CrNi3A价格，上海宝钢12CrNi3锻圆，浙江12CrNi3锻造圆钢，哪里有卖12CrNi3锻件？12CrNi3是什么材料？批发零售12CrNi3供应商——苏州倍徕斯金属。
